N300 WiFi Range Extender Repeater

BE300F-COMPACT

Features
• Extends concurrent WiFi AC and N networks
• N300: 300 Mbps WiFi N bands
• Plugs directly into an electrical outlet
• External antennas and high power amplifiers increase WiFi coverage
• Extender and Access Point modes
• Gigabit wired port
  • Description
  • Specifications

The Repeater is Mainly used for providing free WiFi service in big area such as factory, community, street or etc. The AP/Router can take an existing 2.4GHz wireless signal, repeat and extend it to a longer range where it is too far away for the router or access point to reach. The AP/Router simultaneously supports 2.4G wireless network connection, and it can supports 2.4G transmission speeds of up to 300Mbps. It has 2 x Internal Antennas providing even better wireless performance, transmission rates, stability technology automatically avoids channel conflicts using its channel selection feature.












Standards

IEEE 802.3

IEEE 802.3u

IEEE 802.3ab

IEEE 802.3az

IEEE 802.11b

IEEE 802.11g

IEEE 802.11n

Device Interfaces

Gigabit Ethernet port

WPS Button

AP / Extender

LED indicators

Micro 5pin

Operation Modes

Range Extender (Repeater)

Access Point

Special Features

QoS Management

IPv6 support

WDS support

4 multiple SSID per band

Dynamic DNS support for dyn.com and no-ip.com

Multi-Language interface: English, Chinese, Korean, Russian, others

Access Control

Wireless encryption: WEP, WPA / WPA2-PSK, WPA / WPA2-RADIUS

MAC filter

Frequency

2.4 GHz: FCC: 2.412 ¨C 2.472; ETSI: 2.412 ¨C 2.472 GHz

Antenna Gain

2.4 GHz: 5 dBi (max.) external

Wireless Output Power (EIRP) / Receiving Sensitivity

802.11b: FCC: 20 dBm (typical), CE: 20 dBm (typical) / -83 dBm (typical) @ 11 Mbps

802.11g: FCC: 27 dBm (typical), CE: 20 dBm (typical) / -65 dBm (typical) @ 54 Mbps

802.11n: FCC: 27 dBm (typical), CE: 20 dBm (typical) / -61 dBm (typical) @ 300 Mbps

PowerInput: 100 - 240 V AC, 50/60 Hz
Operating Temperature0 - 40 ¡ãC (32 ¨C 104 ¡ãF)
Operating HumidityMax. 95% non-condensing
